Presentation
- Eco-friendly
- Versatile. Works anywhere, anytime
- Optimal productivity
- Extend duty cycle, increase productivity
Specifications
Eco-friendly
- Electric drive and operation
- Clean and silent operation for use in even the most sensitive work areas
Versatile. Works anywhere, anytime
- Non-marking tires for indoor use
- 4 wheel drive for rough terrain use
- Work silently without work site disruptions
- Non-marking tyres for indoor use
Optimal productivity
- 360° continuous rotation turret (PRO model)
- Quick, proportional and simultaneous movements
- Platform load capacity 550 lb
Extend duty cycle, increase productivity
- Power through a full work shift
- Multi-voltage built in charger
- Low fuel consumption range extending generator
| Working height | 66 ft 4 in |
| Platform height | 60 ft 4 in |
| Horizontal outreach | 39 ft 2 in |
| Up and over clearance | 27 ft 11 in |
| Lift capacity | 550 / 770 lb (2 pers) |
| Platform size | 8 ft x 3 ft |
| Length | 28 ft |
| Width | 7 ft 10 in |
| Height - stowed | 8 ft 2 in |
| Length - transport | 20 ft 1 in |
| Height - transport | 9 ft 10 in |
| Tailswing | 1 ft 4 in |
| Platform rotation | 180° (+ 90° / - 90°) |
| Turntable rotation | 360° continuous |
| Wheelbase | 8 ft 2 in |
| Ground clearance | 1 ft 6 in |
| Tilt alarm | 4 ° |
| Drive speed | 0.4 - 3.1 mph |
| Maximum wind speed rating | 28 mph |
| Gradeability | 45 % |
| Tires - solid, rough terrain | 40.4 x 14.4 in |
| Turning radius - outside | 12 ft 6 in |
| Weight | 21,572 lb |
| Batteries | 12 x 6 V - 435 Ah (C20) |
| Range extender | Kubota Tier 4 Final - 18.5 kW |
| Ground clearance - mini | 0 in |
| Ground clearance - maxi | 0 in |
| Ground clearance - mini | 0 in |
| Ground clearance - maxi | 0 in |
- Haulotte Activ'Lighting System
- Haulotte Activ'Shield Bar 2.0
- Haulotte Activ'Screen
- Telematics solutions
- Haulotte Activ'Energy Management: smart battery management system
- 72 V battery pack (435 Ah)
- Battery charge indicator at upper and lower control boxes
- Multi-voltage charger (110 - 230 V) and integrated range extender (18.5 kW)
- 4 wheel drive: brushless AC motors at each wheel
- 4 wheel steer (LE PRO), 2 wheel steer (LE)
- Front oscillating axle
- Smooth and proportional movements
- Upper control box cover
- Tool tray
- Large modular platform 8 ft x 3 ft with swing gate
- 120 V power to platform
- Swing out engine tray
- Sound and light alarm for tilt and load
- Travel alarm
- Rotating beacon
- Pipe cradle
- Glazier pack
- Biodegradable hydraulic oil
- Cold Weather Package (- 4°F / - 20°C)
- Anti overspeed kit
- Air-line to platform 1/2 inch
- Flashing light
- FASTN, universal and active anchorage
