Presentation
- Outstanding rough terrain driving capabilities
- Optimized serviceability
- Reliable safety
Specifications
Outstanding rough terrain driving capabilities
- Differential wheel lock: 4 wheel drive and steer, oscillating axle
- Up to 4 simultaneous, proportional movements
- Tightest turning radius on the market
- Continuous outreach control
Optimized serviceability
- Modular platform, quick and easy to repair
- Easy access to all components
- Self-diagnosis integrated to the lower control box
Reliable safety
- Haulotte Activ’Shield Bar 2.0
| Working height | 135 ft 7 in |
| Platform height | 129 ft 7 in |
| Horizontal outreach | 65 ft 11 in |
| Up and over clearance | 57 ft 5 in |
| Below ground reach | 4 ft 11 in |
| Lift capacity | 500 lb (2 pers.) |
| Platform size | 8 ft x 3 ft |
| Length | 43 ft |
| Width | 8 ft 2 in |
| Height - stowed | 9 ft 10 in |
| Storage / transport length | 36 ft 1 in |
| Storage / transport height | 12 ft 3 in |
| Vertical jib rotation | 140° (+ 70° / - 70°) |
| Platform rotation | 180° (+ 90° / - 90°) |
| Turntable rotation | 360° continuous |
| Tailswing | 12 ft 9 in |
| Wheelbase | 11 ft 6 in |
| Ground clearance | 15 in |
| Tilt | 4 ° |
| Drive speed | 0.31 - 3.1 mph |
| Maximum wind speed rating | 28 mph |
| Gradeability | 40 % |
| Tyres - foam-filled | 445 / 65 - 22.5 |
| Turning radius - outside axle extended | 18 ft 10 in |
| Power source | Deutz, 55 kW, Turbo, Tier 4 |
| Weight | 52,700 lb |
| Width - with extended axles | 10 ft 10 in |
- Haulotte Activ’Shield Bar 2.0
- Telematics solution
- 4 wheel drive and 4 wheel steer
- Front oscillating axle
- 2 extendable axles
- Fully proportional controls
- 4 simultaneous movements
- Differential wheel lock
- Upper control box protection cover and tool tray in plastic ultra-ruggedized composite
- Modular large platform with swing door entry gate
- Basket compensation ± 10°
- AC power to the platform
- Swing out engine tray
- Tilt / load alarm and light
- Flashing beacon
- Travel alarm
- Electric pump system and emergency descent controls in upper control box
- 12 V battery
- Engine pre-heater with light indicator
- Low fuel level indicator (upper control box)
- Towing hooks
- Non-marking tires
- Air line to platform
- On-board hydraulic generator in 3.7kw or 12 kw
- Biodegradable hydraulic oil
- Hydraulic oil cooler
- Cap with key for diesel tank
- Hydraulic oil in tank and circuit for warm countries
- Cold weather kit
- Pipe cradle
- Glazier kit
- 55W platform worklight
- FASTN, universal and active anchorage
